WBP Atlas Sink 16S240A G1 AM32 ESC 5-16S LiPo 240A Continuous 300A Peak
SKU RS-310 HTS 8806.99 Origin Shenzhen, CN Updated Oct 2026
Price on request
Wholesale pricing is quoted per order. Send the quantity and destination and the trade desk replies within six working hours, EXW Shenzhen.
- MOQ 2 pc — samples welcome
- Sourced equivalent available for private label
- Bench-tested before dispatch
- 12-month warranty, RMA support
- Ships in 24-48h from stock
- Trade desk replies in 6h
description:
The WBP Atlas Sink 16S240A G1 is a heavy‑duty AM32‑based brushless electronic speed controller built for high‑voltage multi‑rotor and large‑size FPV platforms. It supports 5‑16S LiPo battery input, delivering 240A continuous current and up to 300A peak current to handle extreme power‑demand flight scenarios. Equipped with an integrated high‑efficiency heat sink, this ESC greatly improves thermal dissipation under heavy loads, avoiding overheating throttling during long‑duration hard‑pull flights.
Running open‑source AM32 firmware, it brings excellent motor compatibility, rich tuning parameters, fast throttle response and reliable anti‑spark performance. Well‑suited for heavy‑lift FPV, long‑range cruisers, large‑class freestyle drones and industrial multirotor projects. Rigorous factory quality control ensures stable output and low failure rate for both hobby pilots and commercial builders.
brand: WBP
sku: WBP‑ATLAS‑SINK‑16S240A‑G1
offers:
• AM32 open‑source firmware, flexible configuration & great motor compatibility
• 5‑16S wide‑range LiPo voltage support
• 240A continuous / 300A peak current rating for high‑power setups
• Integrated precision heat sink for superior heat dissipation
• Fast throttle response, stable performance under heavy‑load conditions
• Designed for heavy‑lift, long‑range and large‑size FPV multirotors
availability: In Stock, Fast Shipping
Key specifications
| Brand | WBP |
|---|---|
| Department | ESCs, PDB & BEC |
| Cell count | 16S |
| Current rating | 240 A |
| Minimum order | 2 pcs (samples available) |
| Lead time | Ships in 24-48h from stock |
Packing and freight data
| Packaging | Qty per carton | Carton (cm) | Gross weight | CBM |
|---|---|---|---|---|
| Retail box | 4 | 18 × 12 × 6 | 0.42 kg | 0.0013 |
| Inner carton | 15 | 38 × 26 × 22 | 4.6 kg | 0.0217 |
| Export carton | 155 | 58 × 42 × 38 | 21.4 kg | 0.0926 |
Placeholder packing data — confirm with your supplier before quoting freight. CBM is per export carton.
Wholesale questions
What is the minimum order quantity for WBP Atlas Sink 16S240A G1 AM32 ESC?
Stock supply starts at 2 pc. The 10× and 50× quantity breaks are already applied in the price table above.
Can you print our brand on this product?
Not on this specific SKU. For WBP Atlas Sink 16S240A G1 AM32 ESC 5-16S LiPo 240A we supply as-is, but if you need a private-label version we will usually find an equivalent part in the same family that can be branded — send us the requirement.
How is this shipped and how long does it take?
Air express (DHL / FedEx / UPS) is typically 4-7 working days door to door. Larger orders can move by sea or rail with DDP terms so the landed cost is fixed before dispatch.
Is it tested before dispatch?
Every unit is bench-tested and inspected before packing, and we can supply CE / FCC / RoHS documentation and a QC report with the shipment.
